Anlasser 12V/1,2kw 9z f.Kubota Traktor E-TVCS D1462-DI D1462DI-AE D1503-LA V1703-A Kubota Diesel L2500DT L2500F L2650F L2650DT

Anlasser 12V/1,2kw 9z f.Kubota Traktor E-TVCS D1462-DI D1462DI-AE D1503-LA V1703-A Kubota Diesel

 L2500DT L2500F L2650F L2650DT L2650DT-W L2900DT L2900F L2900GST L2950DT L2950DT-W L3130 L3130DT

L3130F L3130GST L3130HST L3300DT L3300F L3300GST L35 34070-16800 34070-16083

Bestellnummer:113893

Denso 128000-8462 128000-8461 128000-8460

Kubota 34070-16081 34070-16803 34070-16801

Servicing: Kubota

Gewicht: 3,66 kg

Volt 12, Kw 1.2, Anzahl der Zähne 9, Getriebetyp GR, Montageflansch 82.30, B+ M8, Ritzelabs. 24.80, Löcher 11.30,

 Loch 2 11.30, Abs./Hinten 118.60, Abs./Vorne 37.20, Abstand mm 105.00, Gesamtlänge mm 178.50,

Kupplungstyp Nass, Ritzeltyp Stahl, Wasserdicht Nein, Öldichtung Nein

B+ M8, Total length 178.50,Gear type GR, Clutch type Wet,Mount. holes 2 (0)A: 82.30 B: 24.80 mm

KUBOTA

GENERATOR SETS

KJS130D All Kubota D1703 Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
KJS130DX All Kubota D1703E Dsl Denso System ND 12 1.2kw 128000-8460 SND0324

TRACTORS - COMPACT

L35TL 96-On Kubota D1703TLB 35HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L35TLB 96-On Kubota D1703TLB 35HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324

L2250F 90-85 Kubota D1302DI 26.5HP Dsl Serial #12401-On ND 12 1.2kw 128000-8460 SND0324
L2500DT 98-On Kubota D1403AE 27HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2500F 98-On Kubota D1403AE 27HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2550DT 90-85 Kubota D1402DIA 29.5HP Dsl Serial #11936-On ND 12 1.2kw 128000-8460 SND0324
L2550DTGST 87-85 Kubota D1402DIA 29.5HP Dsl Serial #11936-On ND 12 1.2kw 128000-8460 SND0324
L2550F 90-85 Kubota D1402DIA 29.5HP Dsl Serial #11936-On ND 12 1.2kw 128000-8460 SND0324
L2550GST 90-86 Kubota D1402DIA 29.5HP Dsl Serial #11936-On ND 12 1.2kw 128000-8460 SND0324
L2650DT 96-90 Kubota D1402DIAE 29HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2650F 93-91 Kubota D1402DIAE 29HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2650GST 93-91 Kubota D1402DIAE 29HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2800DT-F 05-Bk Kubota D1403ME2A 29HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2800DT-R 05-Bk Kubota D1403ME2A 29HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2800F-F 05-Bk Kubota D1403ME2A 29HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2800F-R 05-Bk Kubota D1403ME2A 29HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2800HST 05-Bk Kubota D1403ME2A 29HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2900DT 98-94 Kubota D1503LA 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2900DTGST 98-94 Kubota D1503LA 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2900F 98-94 Kubota D1503LA 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2900GST 98-94 Kubota D1503LA 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2950DT 93-91 Kubota D1462DIAE 30HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2950DTGST 93-91 Kubota D1462DIAE 30HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2950F 93-91 Kubota D1462DIAE 30HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L2950GST 93-91 Kubota D1462DIAE 30HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3010DT 02-98 Kubota D1503LAN 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3010F 02-98 Kubota D1503LAN 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3010GST 02-98 Kubota D1503LAN 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3010HST 02-98 Kubota D1503LAN 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130DT-F 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130DT-R 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130F-F 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130F-R 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130GST-F 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130GST-R 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130HST-C 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130HST-F 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3130HST-R 05-03 Kubota D1503MAE-GST 32HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3300DT 98-94 Kubota D1703-A 35HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3300DTGST 98-94 Kubota D1703-A 35HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3300F 98-94 Kubota D1703-A 35HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3300GST 98-94 Kubota D1703-A 35HP Dsl Denso System ND 12 1.2kw 128000-8460 SND0324
L3400DT-F 05-Bk Kubota D1703MAE2A 34.7HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3400DT-R 05-Bk Kubota D1703MAE2A 34.7HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3400F-F 05-Bk Kubota D1703MAE2A 34.7HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3400F-R 05-Bk Kubota D1703MAE2A 34.7HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3400HST 05-Bk Kubota D1703MAE2A 34.7HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3410DT 02-98 Kubota D1703A 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3410GST 02-98 Kubota D1703A 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3410HST 02-98 Kubota D1703A 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3430DT-F 05-03 Kubota D1703MAE 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3430DT-R 05-03 Kubota D1703MAE 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3430GST-F 05-03 Kubota D1703MAE 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324

L3430GST-R 05-03 Kubota D1703MAE 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3430HST-F 05-03 Kubota D1703MAE 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
L3430HST-R 05-03 Kubota D1703MAE 35.1HP Dsl Denso System ND 12 1.2kw 128000-8462 SND0324
